Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
  • Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
  • Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
  • Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
  • Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs

Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs

Place of Origin Shandong,China
Brand Name HAOBANG
Certification ISO
Model Number 1.2mm TPO waterproof membrane
Product Details
Application:
Roof
Design Style:
Traditional
Width:
1m/2m
Length:
20m/roll
Roofing Application:
Planted Roofs
Wind Uplift Resistance:
4.3 Kpa
Uv Resistance:
≥1500h
Port:
Qingdao
Low Temperature Flexibility:
-40℃
Material:
Thermoplastic Polyolefin
Sample Request:
Free
Transport Packages:
Tray Packaging
Highlight:

Fusible TPO Waterproofing Membrane

,

Metal Roofs TPO Waterproofing Membrane

,

Effortless TPO Waterproofing Membrane

Payment & Shipping Terms
Minimum Order Quantity
1,000 square meters
Price
Price negotiable
Packaging Details
Packed in Roll and on Pallet
Delivery Time
6-7 work days
Payment Terms
T/T,L/C
Supply Ability
680000 square meters per year
Product Description
Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs
Product Attributes
Application Roof
Design Style Traditional
Width 1m/2m
Length 20m/roll
Roofing Application Planted Roofs
Wind Uplift Resistance 4.3 Kpa
Uv Resistance ≥1500h
Port qingdao
Low Temperature Flexibility -40℃
Material Thermoplastic Polyolefin
Sample Request free
Transport Packages Tray Packaging
Product Description
Product Name 1.2mm TPO Roofing Membrane (Smooth Version)
Material TPO
Color White

Composed of thermoplastic polyolefin (TPO), integrating the fusibility of propylene-alpha-olefin copolymer resins via cutting-edge polymerization techniques and the robustness of polypropylene resins, Haobang TPO-H is a uniform multi-layered composite thermoplastic polyolefin polymer waterproof sheet crafted by sophisticated processing methods, applied for the meticulous treatment of open rooftops.

Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs 0 Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs 1
Technical Data Sheet
GB27789-2011 TPO Waterproofing Membrane (Type H)
Tensile Properties Value
Tensile strength ≥ 12 MPa
Elongation at rapture 500 %
Dimensional change rate on heating 2 %
Low temperature bending -40℃ No Cracks
Watertightness 0.3 MPa, 2h Watertight
Impact resistance 0.5 kg*m, No water leakage
Peel strength at joints 4.0 N/mm or damaged
Right angle tear strength 60 N/mm
Water Absorption Rate (70℃168h) 4 %
Heat aging (115℃)
Time 672 h
Appearance No blistering, cracks, delamination, sticking or voids
Tensile strength retention ≥ 90 %
Elongation retention at rapture ≥ 90 %
Low temperature bendability -40℃, No Cracks
Chemical resistance
Appearance No blistering, cracks, delamination, sticking or voids
Tensile strength retention ≥ 90 %
Elongation retention at rapture ≥ 90 %
Low temperature bendability -40℃, No Cracks
Artificial climate accelerates aging
Time 2500 h
Appearance No blistering, cracks, delamination, sticking or voids
Tensile strength retention 90 %
Elongation retention at break ≥ 90 %
Low temperature bendability -40℃, No Cracks
Wind uplift resistance 4.3Kpa 90
Application
  • Transportation nodes: airport concourses, bullet train stations, bus terminals
  • Institutional edifices: trade fair complexes, galleries, arenas
  • Modern infrastructure: data hubs, distribution centers
  • Manufacturing facilities: automotive, semiconductor, engineering, cigar factories
Advantages
  • Outstanding fusibility
  • Superb cold-weather malleability
  • Superlative dimensional consistency
  • Exceptional stretching ability
  • Robust shock tolerance
  • High solar reflectance
  • Eco-conscious, reusable
  • Sustained UV resilience
Specification

Every single standard roll is separately wrapped in polyethylene film. The width measures 2.0 meters, and the length is determined by the membrane's thickness.

  • 0.8mm 30m (Approximate weight per roll: 48 - 50 kilograms)
  • 1.2mm 25m (Approximate weight per roll: 62 - 64 kilograms)
  • 1.5mm 20m (Approximate weight per roll: 62 - 64 kilograms)
  • 1.8mm 15m (Approximate weight per roll: 56 - 58 kilograms)
  • 2.0mm 15m (Approximate weight per roll: 62 - 64 kilograms)
Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs 2 Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs 3 Superior Resilient TPO Membrane Waterproofing Fusible Effortless to Install for Metal Roofs 4
FAQ
Q: Do you offer complimentary samples?
A: Indeed, samples sized under 1M2 or weighing 1KG or less are provided without cost, but the buyer is responsible for covering the shipping fees.
Q: Can I utilize my own logistics provider?
A: Absolutely, we're happy to work with your designated shipping agent.
Q: Is there room for price adjustment?
A: Certainly, significant orders will receive a generous discount.
