Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping
  • Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping
  • Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping
  • Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping

Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping

Place of Origin Shandong,China
Brand Name HAOBANG
Certification ISO
Model Number 1.5mm self adhesive waterproof membrane
Product Details
Waterproofing Type:
Waterproof
Temperature Range:
-20°C To 80°C
Thickness:
1.5mm
Weather Resistance:
Good
Design Style:
Traditional
Material:
Polymer Modified Bitumen
Advantages:
Outstanding Tensile Strength
Impermeability:
0.3Mpa, 2-hour Impermeable
Applicability:
Industrial Building Roofs
Shape:
Roll Material
Highlight:

Self-Bonding Asphalt Waterproof Membrane

,

Seamless Overlapping Asphalt Waterproof Membrane

,

Fire Hazard Elimination Asphalt Waterproof Membrane

Payment & Shipping Terms
Minimum Order Quantity
500 square meters
Price
Price negotiable
Packaging Details
Packed in Roll and on Pallet
Delivery Time
5-6 work days
Payment Terms
T/T
Supply Ability
800000 square meters per year
Product Description
Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping
Product Attributes
Attribute Value
Waterproofing Type Waterproof
Temperature Range -20°C To 80°C
Thickness 1.5mm
Weather Resistance Good
Design Style Traditional
Material Polymer modified bitumen
Advantages Outstanding tensile strength
Impermeability 0.3Mpa, 2-hour Impermeable
Applicability Industrial building roofs
Shape Roll material
Product Description

Engineered as a premium-grade membrane for outstanding field performance in a wide range of application scenarios, the Bitumen Self-Adhesive Waterproof Membrane is composed of a high-strength co-extruded protective layer, advanced modified bitumen compound, and a backing release liner that safeguards the adhesive properties. When installing, the release liner can be easily removed, allowing the modified bitumen to securely adhere to substrates made from different materials.

Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping 0 Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping 1
Application
  • Ideal for waterproofing underground structures and both concrete and timber roofing surfaces in commercial and residential buildings.
  • It is also well-suited for waterproofing and damp-proofing other building elements that demand materials with excellent tensile and tear resistance, as well as high stretchability.
Advantages
  • Outstanding physical properties: remarkable tensile strength, adaptable sealing at nail penetrations and fissures, and broad compatibility with diverse substrates.
  • Cold-applicable design: eliminates fire hazards; the self-bonding asphalt ensures robust adhesion and seamless overlapping.
  • Premium cross-laminated surface film: provides dimensional integrity, superior tear resilience, and enhanced protection against punctures and impacts.
  • Versatile use in intricate areas, integrates well with other waterproofing solutions.
  • Hassle-free repair process: strong substrate adhesion restricts water spread even when leaks occur, allowing for swift damage identification and immediate restoration.
Technical Data Sheet
No. Property Value
1 Tensile Properties

Tensile force /(N/50mm)

Longitudinal: ≥200

Transverse

Elongation at break/ %

Longitudinal: ≥250

Transverse

2 Peel Strength between Membranes (N/mm)

No treatment: ≥1.0

Heat treatment: ≥0.8

3 Dimensional Change Rate/ %

Longitudinal: ≤±1.0

Transverse

4 Peel Strength (bond to cement mortar) /(N/mm)

No treatment: ≥1.5

Heat treatment: ≥1.0

5 Heat Aging (80°C,168h)

Tensile retention/%: ≥90

Elongation retention/%: ≥80

Low Temperature Flexibility: No crack at -18°C

6 Bonding Retention /min ≥30
7 Heat Resistance 70°C, 2h, no blister or flow
8 Low Temperature Flexibility No crack at -20°C (-4°F)
9 Water Impermeability No water leakage in 2 hours(0.3Mpa, 120min)

REMARK: All the test items according to China Standard GB/T 35467-2017.

Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping 2 Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping 3 Self-Bonding Asphalt Waterproof Membrane for Basement Subway Tunnel with Fire Hazard Elimination and Seamless Overlapping 4
FAQ
Q: Do you offer free samples?

A: Indeed. Samples measuring less than 1M² or weighing under 1KG are provided at no cost, though the purchaser is responsible for shipping fees.

Q: Am I allowed to use my own shipping company?

A: Absolutely. You're free to utilize your preferred shipping agent.

Q: Is there a possibility for price adjustment?

A: Substantial orders are eligible for attractive price reductions.
