Smooth Version TPO Roof Membrane Single Ply Roofing Membrane TPO Waterproof Membrane
Product Description
| Product Name |
1.5mm TPO Roofing Membrane (Smooth Version) |
| Material |
TPO |
| Color |
White |
The TPO Waterproof Membrane is available in two convenient Coil Width options of 1m and 2m, allowing for flexibility in installation and accommodating various project requirements.
In addition, this Thermoplastic Polyolefin Waterproof Membrane exhibits excellent Low Temperature Bending capabilities, with a remarkable tolerance of -40℃ without developing any cracks. This feature ensures that the membrane remains flexible and intact even in extremely cold conditions, preventing potential damage and ensuring long-term performance.
Whether used for roofing or waterproofing applications, the TPO Waterproof Membrane offers a reliable and effective solution that combines strength, durability, and flexibility. Its superior performance characteristics make it a popular choice for both residential and commercial projects where quality and longevity are essential.
Technical Data Sheet
| GB27789-2011 TPO Waterproofing Membrane(Type H) |
| Tensile Properties |
|
|
Value |
| Tensile strength |
≥ |
MPa |
12 |
| Elongation at rapture |
|
% |
500 |
| Dimensional change rate on heating |
|
% |
2 |
| Low temperature bending |
|
- |
-40℃No Cracks |
| Watertightness |
|
- |
0.3 MPa,2h Watertight |
| Impact resistance |
- |
- |
0.5 kg ·m, No water leakage |
| Peel strength at joints |
|
N/mm |
4.0 or damaged |
| Right angle tear strength |
|
N/mm |
60 |
| Water Absorption Rate(70℃168h) |
|
% |
4 |
| Heat aging (115℃) |
|
|
|
| Time |
- |
h |
672 |
| Appearance |
- |
- |
No blistering,cracks,delamination,sticking or voids |
| Tensile strength retention |
≥ |
% |
90 |
| Elongation retention at rapture |
≥ |
% |
90 |
| Low temperature bendability |
- |
- |
-40, No Cracks |
| Chemical resistance |
|
|
|
| Appearance |
- |
- |
No blistering,cracksdelaminationsticking or voids |
| Tensile strength retention |
≥ |
% |
90 |
| Elongation retention at rapture |
≥ |
% |
90 |
| Low temperature bendability |
- |
- |
-40℃,No Cracks |
| Artificial climate accelerates aging |
|
|
|
| Time |
- |
h |
2500 |
| Appearance |
- |
- |
No blisteringcracks,delamination,sticking or voids |
| Tensile strength retention |
|
% |
90 |
| Elongation retention at break |
≥ |
% |
90 |
| Low temperature bendability |
|
|
-40℃, No Cracks |
| Wind uplift resistance |
|
4.3Kpa |
90 |
Application
- Transportation hub: airport terminal, high-speed railway station, passenger terminal...
-
Public buildings: convention and exhibition centers, exhibition halls, stadiums...
-
New infrastructure: big data center, logistics center...
-
Industrial plants: automobiles, electronics, machinery, tobacco factories...
Advantages
-
Excellent weldability;
-
Good low temperature flexibility;
-
Excellent dimensional stability;
-
Good elongation property;
-
Good impact resistance;
-
High sunlight reflectivity;
-
Energy saving and environmental friendly, recyclable;
-
Long-term resistance to UV exposure
Specification
Each standard roll is individually encapsulated in polyethylene film. The width is 2.0m, and the length varies according to the thickness of the membrane.
- 0.8mm 30m(Each roll weighs about 48-50kg)
- 1.2mm 25m(Each roll weighs about 62-64kg)
- 1.5mm 20m(Each roll weighs about 62-64kg)
- 1.8mm 15m(Each roll weighs about 56-58kg)
- 2.0mm 15m(Each roll weighs about 62-64kg)
